Titanium seamless tube/Titanium pipe

Titanium seamless tube is processed by the breakdown of titanium ingot, extruding to titanium tube billet. Then produce titanium tubes to appropriate size with series of processes such as multiple rolling, annealing, pickling, and grinding technology.

Product Description

Titanium  tube is processed by the breakdown of titanium ingot, extruding to titanium tube billet. Then produce titanium tubes to appropriate size with series of processes such as multiple rolling, annealing, pickling, and grinding technology.
Titanium welded tube is by selecting a suitable thickness of the high quality cold rolled titanium plate, after the process of flattening, cutting and washing, then rolled up titanium plate into tubular, welding by the whole automatic welding equipment. Our advanced welding equipment guaranteed the quality of welding. Ultimately help to produce the excellent quality titanium tube.

Titanium seamless tube/Titanium pipe

MaterialCP titanium, Titanium alloy
GradeGr1, Gr2, Gr4, Gr5, Gr7, Gr9, Gr11, Gr12, Gr16, Gr23 etc
SizeOD: 3~1500mm, WT: 0.2~25mm: Length: ≤19000mm
StandardASTM B338, ASTM B337, ASTM B861, ASTM B862 etc
StatusAnnealed (M)
TechnologyRolling, Welding, Machining


Technology Comparison

Titanium seamless tubeGrade: Gr1, Gr2, Gr7, Gr9, Gr11, Gr12, Gr16 etc
Outer diameter: 3~110mm
Wall thickness: 0.1~5.5mm
Length: ≤19000mm
Titanium seamless tube
Grade: Gr1, Gr2, Gr7, Gr9, Gr11, Gr12, Gr16 etc
Outer diameter: 3~110mm
Wall thickness: 0.1~5.5mm
Length: ≤19000mm
titanium alloy seamless tube

Grade: Gr5, Gr23

Outer diameter: 20~110mm
Wall thickness: 1~50mm
Length: ≤3000mm
Manufacturing process: Drilling, Hot Rolling




Application

1.Shell and tube heat exchanger, condenser, evaporator, pipeline, etc

2.Impressed current cathodic protection
3.Seawater desalination equipment
4.Bike rack
5.Marine pressure tube
6.Oil drilling pressure tube
